KNIFE EDGE GATE VALVE ‘WIKA’ MODEL

BODY	IS 210 Gr. FG 200 \| WCB \| WC1 \| WC6 \| WC9 \| LCB \| CF8 \| CF8M \| CF3 \| CF3M
SEAT	NITRILE \| METAL TO METAL
INSP & TEST STD	MSS SP -81
KNIFE PLATE	ASTM A 351 Gr CF8 \| CF8M \| CI \| WCB \| CF3 \| CF3M
LEAKAGE CLASS	CLASS – IV
ENDS	FLANGED \| LUGGED TO ASME B16.5 RF (150#)
OPERATION	MANUAL \| CHAIN WHEEL OPERATED \| CYLINDER OPERATED
HYD-TEST PRESSURE	BODY : 156 Psig (11 Kg/Cm ²)
	SEAT : 40 Psig (2.8 Kg/Cm ²)
SIZE RANGE	40 MM TO 750 MM

Category: Gate Valve Tag: Gate Valve

Additional information

Weight	12 kg
Dimensions	42 × 12 × 42 cm
